MRC ANGULAR CONTACT BALL BEARINGS - 7409PJDU

$109.99 $210.99
Shipping calculated at checkout.

Delivery and Shipping

Shipping is automatically calculated at checkout.

In store pickup is sometimes the only option. These products are noted as such in our listings.

Some items have been set up so that they require a shipping quote.  Please fill out the appropriate form on the product's page and we will respond within 24-48 hours with a freight quote.

What we ship is by best carrier, some products prepaid and others not, due to our large variances in product lines, physical sizes and weight.

At checkout you will be prompted for shipping alternatives dependent on these parameters. Products which fit standardized packaging may also have calculated shipping costs by weight and volume on our website.

In all cases our staff audits for the best shipping cost and if necessary will contact our customer with recommendations.

Freight/Palleted items that are not accepted by the recipient or are sent back to us due to undeliverable address may be refunded, but the return shipping fees will be deducted from the overall amount of refund.

All returned items are subject to a 10% handling fee.

MRC ANGULAR CONTACT BALL BEARINGS - 7409PJDU

Description

MRC ANGULAR CONTACT BALL BEARINGS - 7409PJDU

PRODUCT DISCLOSURE:

All products were acquired by Freeman Liquidators from a sale of merchandise subject to a commercial insurance loss. Freeman Liquidators is a secondary seller of products, is not affiliated with or sponsored by the manufacturer of the products and is not a manufacturer authorized seller of the products. Sale of this product by Freeman Liquidators is not subject to the policies of the manufacturer. Any warranty offered by the manufacturer is not available to you as the purchaser. All products are NEVER USED but external packaging will have damage. Some items may be placed into other packaging to ensure safe shipping. All items are opened for inspection prior to shipment to ensure the best quality of products. Freeman Liquidators guarantees your satisfaction. If you are not completely satisfied with a purchased product, within 30 days from the date of purchase, return the product in its packaging and Freeman Liquidators will fully refund your money.

Additional Description

Item Details
Manufacturer: MRC Bearing Service
Weight: 3.781 lbs.
Product Name: 7400-PJD Heavy Series Duplex Ball Bearing
Description: Single Row Angular Contact Bearing, 45 mm ID x 120 mm OD x 29 mm Wide, Open, Standard Precision (ABEC 1), Brass / Bronze Cage, Normal Clearance (C0), 40° Contact Angle
Specifications
Inch/Metric Metric Bore Bore Type Round Bore
I.D. 45 mm O.D. [Min]
O.D. [Max] O.D. 120 mm
Width [Min] Width [Max]
Width 29 mm Enclosure Open
Rows of Balls Single Material Steel
O.D. Type Straight Bearing Type Angular Contact
Precision Standard Radial Internal Clearance Specification Normal Clearance
Ambient Temperature Range [Min] Ambient Temperature Range [Max]
Ball Material Steel Cage Type Metal
Capacity Standard Capacity Contact Angle 40°
Guide Type Lubrication
Outer Ring Width 29 mm Precision Level Standard (ABEC 1)
Preload Level None Seal Material None
Seal Type Unsealed Seal Width
Dynamic Load Rating 19200 lbf Static Load Rating [Max] 12800 lbf
Ball Dia. Bearing Design
Bore B Cage Material Brass/Bronze
Collar No. Collar O.D.
Collar Width Corner Radius [Min]
Eccentric Collar Offset Fillet Radius 2 mm
Flange O.D. [Max] Flange O.D.
Flange Width [Max] Flange Width
Flush Ground Housing Shoulder Diameter [Min]
Housing Shoulder Diameter [Max] Housing Shoulder Diameter
Industry Standard Part # Inner Ring O.D.
Inner Ring Offset Inner Ring Width 29 mm
Internal Design Universal Mounting Limiting Speed
Limiting Speed - Grease 5300 rpm Limiting Speed - Oil 6900 rpm
Limiting Speed - Sealed Locking Device No Locking Device
Lube Hole Center Lubricant Oil Preservative
Misalignment Range No. in Set Single Bearing
No. of Balls O.D. (B)
Outer Ring Outer Ring Inner Diameter
Outer Ring Size Peak Running Torque (mg-mm)
Peak Starting Torque (mg-mm) Pre Lubricant
Preload Amount Radial Internal Clearance Normal
Radial Load Rating [Max] Radial Rigidity (lbf/µm)
Reference Speed Seal O.D.
Seal Protection Width Seating Washer
Series Set Screw Offset
Set Screw Size Shaft Shoulder Diameter [Min]
Shaft Tolerance Snap Ring No Snap Ring
Snap Ring O.D. Snap Ring Offset
Snap Ring Thickness Special Features
Stamping Static Thrust Load Rating [Max]
Temperature Range [Min] Temperature Range [Max] 450 °F
Use With
Product Information
General
MRC angular contact bearings with a PJ suffix have one heavy race shoulder on the outer ring, opposing one heavy race shoulder and on recessed race shoulder on the inner ring. Because of this construction, it is possible for this bearing to incorporate a greater number of balls than a deep groove nonfilling notch bearing. The combination of maximum ball complement, optimum race groove depth, and the 40° contact angle results in high thrust load carrying capacity. 7000-PJ bearings are particularly suitable for positions where the thrust is always present in one direction. It should not be used where the bearing is subjected to radial load only, or combined radial and thrust load where the radial load is predominant. When heavy thrust must be taken in both directions, and angular contact bearing may be mounted in a duplex arrangement with another angular contact bearing or with a 9000-UP split inner ring bearing. 7000-PJ bearings are available with either peressed brass or machined brass, ball centered cages. The low shoulder diameters on the nonthrust sides of inner and outer rings, combined with large clearances between the land diameters and the cage, allow for large quantities of oil to flow through the bearings. The increased oil flow reduces operating temperature and theoretically increases bearing life. ABEC Grade 3 bore tolerances reduce the range of interference fits between the shaft and bearing bore. These tighter tolerances result in closer control of preload and minimize the risk of thermal runaway. 7400-PJ and PJD Series bearings are similar to the 7200-PJ and 7300-PH Series but are heavier sectioned and are used for very heavy thrust loads or combined radial and thrust loads where thrust is predominant.
