Siemens GNF222RA — 60A General Duty Safety Switch, 240V, 2‑Pole, Non‑Fusible, NEMA 3R

The Siemens GNF222RA is a 60‑amp, 240‑volt, 2‑pole, non‑fusible general‑duty safety switch designed for residential and light commercial disconnecting means. Built with a NEMA 3R rainproof enclosure, it is suitable for outdoor installations and service‑entrance applications.

Featuring a quick‑make, quick‑break mechanism, visible double‑break blades, and oversized mechanical lugs, this switch delivers reliable performance and meets UL98 and NEMA KS‑1 standards.

Key Features

• 60A general‑duty safety switch

• 2‑pole, 2‑wire, non‑fusible design

• 240V AC rated

• NEMA 3R outdoor enclosure for rainproof protection

• Quick‑make, quick‑break switching action

• Double‑break visible blade design for safety and inspection

• Suitable for service‑entrance use with optional neutral kit HN22A

• Meets UL98, UL50, and NEMA KS‑1 standards

Specifications

• Model: GNF222RA

• Amperage: 60A

• Voltage: 240V AC / 250V DC max

• Poles: 2

• Enclosure: NEMA 3R rainproof

• Wire Range: Oversized mechanical lugs (per Siemens VBII spec)

• Short‑Circuit Rating:

  • 10,000 AIC with Class H/K fuses

  • 100,000 AIC with Class R fuses

• Horsepower Rating:

  • 10 HP @ 240V AC (1‑phase)

Common Uses

• Outdoor disconnect

• HVAC equipment

• Pump and motor loads

• Service‑entrance disconnect (with neutral kit)

• Light commercial and residential power shutoff

Barcode: 804766753381
