NTN 6314LLBC3/EM MEDIUM SIZE BEARINGS

$129.99 $321.75
Shipping calculated at checkout.

Description

NTN 6314LLBC3/EM MEDIUM SIZE BB(STD) D>80<203.2

PRODUCT DISCLOSURE:

All products were acquired by Freeman Liquidators from a sale of merchandise subject to a commercial insurance loss. Freeman Liquidators is a secondary seller of products, is not affiliated with or sponsored by the manufacturer of the products and is not a manufacturer authorized seller of the products. Sale of this product by Freeman Liquidators is not subject to the policies of the manufacturer. Any warranty offered by the manufacturer is not available to you as the purchaser. All products are NEVER USED but external packaging will have damage. Some items may be placed into other packaging to ensure safe shipping. All items are opened for inspection prior to shipment to ensure the best quality of products. Freeman Liquidators guarantees your satisfaction. If you are not completely satisfied with a purchased product, within 30 days from the date of purchase, return the product in its packaging and Freeman Liquidators will fully refund your money.

  • BRAND: NTN BEARING
  • MODEL: 6314LLBC3/EM
  • CONDITION: NEW

Technical Specifications

Type

Deep Groove Ball Bearing

Bore Type

Round

Material

High Carbon Chrome Steel

Cage Type

Pressed

Cage Material

Steel

Ball Material

Steel

Limiting Speed - Grease

4600 RPM

Seal Type

Non-Contact

Seal Material

Nitrile Rubber

Precision

ISO Class 0

Configuration

One

Factor

13.2

Radial Internal Clearance

C3

Static Load Rating

15300 lbf68000 N68.00 kN

Dynamic Load Rating

23400 lbf104000 N104.00 kN

Enclosure

Double Sealed

Weight

5.710 lb2.590 kg

Operating Temperature Range

-40 to 250 F-40 to 120 C

Dimensional Specifications


Single Row Radial Ball Bearing - Double Sealed (Non-Contact Rubber Seal) - Dimensions

d

2.7559 in70.000 mm

D

5.9055 in150.000 mm

B

1.3780 in35.000 mm

r

0.0827 in2.100 mm

r1

0.0197 in0.500 mm

da min

3.1890 in81.000 mm

da max

3.6417 in92.500 mm

Da max

5.4724 in139.000 mm

ras max

0.0787 in2.000 mm
