Wago, 750-612, Power Supply, 0 … 230 V, AC/DC - NEW NO BOX
Product Overview
This supply module provides the I/O modules with the corresponding supply potential.
The maximum current provided by the supply module is 10 A. When configuring the system, the total current must not be exceeded.
Should higher currents be necessary, an intermediate supply module must be added to the assembly.
Signal type | Voltage |
Signal type (voltage) | 0 … 230 VAC/DC |
Supply voltage (system) | 5 VDC; via data contacts |
Supply voltage (field) | 230 VAC/DC (-15 … +10 %); via power jumper contacts (power supply via CAGE CLAMP® connection; transmission via spring contact) |
Number of outgoing power jumper contacts | 3 |
Current carrying capacity (power jumper contacts) | 10A |
Connection data
Connection technology: field supply | 6 x CAGE CLAMP® |
Connection type 1 | Field supply |
Solid conductor | 0.08 … 2.5 mm² / 28 … 14 AWG |
Fine-stranded conductor | 0.08 … 2.5 mm² / 28 … 14 AWG |
Strip length | 8 … 9 mm / 0.31 … 0.35 inches |
Physical data
Width | 12 mm / 0.472 inches |
Height | 100 mm / 3.937 inches |
Depth | 69.8 mm / 2.748 inches |
Depth from upper-edge of DIN-rail | 62.6 mm / 2.465 inches |
Mechanical Data
Mounting type | DIN-35 rail |
Material Data
Color | light gray |
Housing material | Polycarbonate; polyamide 6.6 |
Fire load | 1.164MJ |
Weight | 43.6g |
Conformity marking | CE |
Environmental requirements
Ambient temperature (operation) | 0 … +55 °C |
Surrounding air temperature (storage) | -25 … +85 °C |
Protection type | IP20 |
Pollution degree (5) | 2 per IEC 61131-2 |
Operating altitude | 0 … 2000 m / 0 … 6562 ft |
Mounting position | horizontal (standing/lying); vertical |
Relative humidity (without condensation) | 95% |
Vibration resistance | 4g per IEC 60068-2-6 |
Shock resistance | 15g per IEC 60068-2-27 |
EMC immunity to interference | per EN 61000-6-2, marine applications |
EMC emission of interference | per EN 61000-6-4, marine applications |
Exposure to pollutants | Per IEC 60068-2-42 and IEC 60068-2-43 |
Permissible H2S contaminant concentration at a relative humidity |
10ppm |
Permissible SO2 contaminant concentration at a relative humidity |
25ppm |
Commercial data
Product Group | 15 (Remote I/O) |
eCl@ss 10.0 | 27-24-26-10 |
eCl@ss 9.0 | 27-24-26-10 |
ETIM 8.0 | EC001600 |
ETIM 7.0 | EC001600 |
PU (SPU) | 1 pcs |
Packaging type | box |
Country of origin | DE |
GTIN | 4045454393793 |
Customs tariff number | 85389091890 |
