Wago, 750-612, Power Supply, 0 … 230 V, AC/DC - NEW NO BOX

$39.99 $54.99
Shipping calculated at checkout.

Description

Wago, 750-612, Power Supply, 0 … 230 V, AC/DC - NEW NO BOX

PRODUCT DISCLOSURE:

All products were acquired by Freeman Liquidators from a sale of merchandise subject to a commercial insurance loss. Freeman Liquidators is a secondary seller of products, is not affiliated with or sponsored by the manufacturer of the products and is not a manufacturer authorized seller of the products. Sale of this product by Freeman Liquidators is not subject to the policies of the manufacturer. Any warranty offered by the manufacturer is not available to you as the purchaser. All products are NEVER USED but external packaging will have damage. Some items may be placed into other packaging to ensure safe shipping. All items are opened for inspection prior to shipment to ensure the best quality of products. Freeman Liquidators guarantees your satisfaction. If you are not completely satisfied with a purchased product, within 30 days from the date of purchase, return the product in its packaging and Freeman Liquidators will fully refund your money.

Product Overview

This supply module provides the I/O modules with the corresponding supply potential.



The maximum current provided by the supply module is 10 A. When configuring the system, the total current must not be exceeded.



Should higher currents be necessary, an intermediate supply module must be added to the assembly.



Signal type Voltage
Signal type (voltage) 0 … 230 VAC/DC
Supply voltage (system) 5 VDC; via data contacts
Supply voltage (field) 230 VAC/DC (-15 … +10 %); via power jumper contacts (power supply via CAGE CLAMP® connection; transmission via spring contact)
Number of outgoing power jumper contacts 3
Current carrying capacity (power jumper contacts) 10A
Connection data
Connection technology: field supply 6 x CAGE CLAMP®
Connection type 1 Field supply
Solid conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Fine-stranded conductor 0.08 … 2.5 mm² / 28 … 14 AWG
Strip length 8 … 9 mm / 0.31 … 0.35 inches
Physical data
Width 12 mm / 0.472 inches
Height 100 mm / 3.937 inches
Depth 69.8 mm / 2.748 inches
Depth from upper-edge of DIN-rail 62.6 mm / 2.465 inches
Mechanical Data
Mounting type DIN-35 rail
Material Data
Color light gray
Housing material Polycarbonate; polyamide 6.6
Fire load 1.164MJ
Weight 43.6g
Conformity marking CE
Environmental requirements
Ambient temperature (operation) 0 … +55 °C
Surrounding air temperature (storage) -25 … +85 °C
Protection type IP20
Pollution degree (5) 2 per IEC 61131-2
Operating altitude 0 … 2000 m / 0 … 6562 ft
Mounting position horizontal (standing/lying); vertical
Relative humidity (without condensation) 95%
Vibration resistance 4g per IEC 60068-2-6
Shock resistance 15g per IEC 60068-2-27
EMC immunity to interference per EN 61000-6-2, marine applications
EMC emission of interference per EN 61000-6-4, marine applications
Exposure to pollutants Per IEC 60068-2-42 and IEC 60068-2-43
Permissible H2S contaminant concentration at a relative humidity 75 % 10ppm
Permissible SO2 contaminant concentration at a relative humidity 75 % 25ppm
Commercial data
Product Group 15 (Remote I/O)
eCl@ss 10.0 27-24-26-10
eCl@ss 9.0 27-24-26-10
ETIM 8.0 EC001600
ETIM 7.0 EC001600
PU (SPU) 1 pcs
Packaging type box
Country of origin DE
GTIN 4045454393793
Customs tariff number 85389091890
