Setra DPT2300-025D-V Wet/Wet Differential Pressure Transducer

$229.99
Shipping calculated at checkout.

Delivery and Shipping

Shipping is automatically calculated at checkout.

In store pickup is sometimes the only option. These products are noted as such in our listings.

Some items have been set up so that they require a shipping quote.  Please fill out the appropriate form on the product's page and we will respond within 24-48 hours with a freight quote.

What we ship is by best carrier, some products prepaid and others not, due to our large variances in product lines, physical sizes and weight.

At checkout you will be prompted for shipping alternatives dependent on these parameters. Products which fit standardized packaging may also have calculated shipping costs by weight and volume on our website.

In all cases our staff audits for the best shipping cost and if necessary will contact our customer with recommendations.

Freight/Palleted items that are not accepted by the recipient or are sent back to us due to undeliverable address may be refunded, but the return shipping fees will be deducted from the overall amount of refund.

All returned items are subject to a 10% handling fee.

Setra DPT2300-025D-V Wet/Wet Differential Pressure Transducer

Description

  • PRODUCT DISCLOSURE:

    All products were acquired by Freeman Liquidators from a sale of merchandise subject to a commercial insurance loss. Freeman Liquidators is a secondary seller of products, is not affiliated with or sponsored by the manufacturer of the products and is not a manufacturer authorized seller of the products. Sale of this product by Freeman Liquidators is not subject to the policies of the manufacturer. Any warranty offered by the manufacturer is not available to you as the purchaser. All products are NEVER USED but external packaging will have damage. Some items may be placed into other packaging to ensure safe shipping. All items are opened for inspection prior to shipment to ensure the best quality of products. Freeman Liquidators guarantees your satisfaction. If you are not completely satisfied with a purchased product, within 30 days from the date of purchase, return the product in its packaging and Freeman Liquidators will fully refund your money.

    Setra DPT2300-025D-V Wet/Wet Differential Pressure Transducer
  • new
  • *Exterior Packaging May Have Damages, but the item is in new/unused condition.  Opened for inspection prior to shipment.
  • Ranges: 0- ±5 psid up to 0-100 psid Liquid or Gases Both Sides

    Setra Systems Model 230 is a high output, low differential pressure transducer designed for wet to wet differential pressure measurements of liquids or gases. A fast-response capacitance sensor and signal conditioned electronic circuitry provide a highly accurate, linear analog output proportional to pressure. Both unidirectional and bidirectional pressure ranges are available for applications with line pressure up to 250 psig.

    A unique isolation system transmits the motion of the differential pressure sensing diaphragm from the high line pressure environment (e.g. corrosive liquids) to the dry (air) enclosure where it moves one of a pair of capacitance plates proportionally to the diaphragm movement. All parts exposed to the pressure media are stain-less steel and elastomer seals. The 230 has a NEMA 4/IP65 rated package to withstand environmental effects. This system responds to pressure changes approximately 20 times faster than conventional fluid-filled transducers. The electronic circuit linearizes output vs. pressure and compensates for thermal effects of the sensor.

    The Model 230 can be supplied with a 3-valve manifold assembly (ordered as Pressure Fitting Code V) to protect against excessive differential overpressure, which may occur during installation, start-up or shut-down. The 230 bleed ports allow for total elimination of air in the line and pressure cavities. The manifold’s rugged, yet compact, construction requires minimum space for installation.

    Applications
    • Process Control
    • Energy Management Systems
    • Flow measurement of various gases or liquids
    • Liquid level measurement of pressurized vessels
    • Pressure Drop Across Filters

    Features
    • NEMA 4/IP65 rating
    • 3-valve Manifold Assembly
    • High Accuracy
    • Fast Response
    • Gas and Liquid Compatible
    • Low Differential Ranges
    • Low Line Pressure Effect
    • No Liquid Fill Diaphragms
