TTC 67-420-220 40 NS TAPER SPACER TYPE MILLING MACHINE ARBOR
PRODUCT DISCLOSURE:
All products were acquired by Freeman Liquidators from a sale of merchandise subject to a commercial insurance loss. Freeman Liquidators is a secondary seller of products, is not affiliated with or sponsored by the manufacturer of the products and is not a manufacturer authorized seller of the products. Sale of this product by Freeman Liquidators is not subject to the policies of the manufacturer. Any warranty offered by the manufacturer is not available to you as the purchaser. All products are NEVER USED but external packaging will have damage. Some items may be placed into other packaging to ensure safe shipping. All items are opened for inspection prior to shipment to ensure the best quality of products. Freeman Liquidators guarantees your satisfaction. If you are not completely satisfied with a purchased product, within 30 days from the date of purchase, return the product in its packaging and Freeman Liquidators will fully refund your money.
Precision Milling Machine Arbors 30-40-50 Taper - Length of Shoulder To Nut: 20", Arbor: 41-1/4 - B20-3, 67-420-220
ITEM #: 67-420-220
Brand: TTC
Taper: 40 NS
Arbor Diameter: 1-1/4"
Arbor: 41-1/4 - B20-3
Hardened, ground and accurate
FEATURES
- Arbors and spacers have standard size keyways.
- Has pilot with 23/32" diameter x 1-3/4" length.
- Draw bar type.
| PRODUCT SPECIFICATIONS | |
|---|---|
| BRAND | TTC |
| TAPER | 40 NS |
| ARBOR DIAMETER | 1-1/4" |
| ARBOR | 41-1/4 - B20-3 |
| LENGTH OF SHOULDER TO NUT | 20" |
| STYLE | B |
| TYPE | Milling Machine Arbor |
| BUSHING FURNISHED | 1 |
| DIMENSIONS OF RUNNING | 1-7/8" x 3-1/8" |
| DRAWBAR THREAD | 5/8"-11 |
| MODEL # | 67-420-220 |
| PROP. 65 | Yes |
| SHANK | 40 N.S. |
| WEIGHT | 19 lbs. |
| COUNTRY OF ORIGIN | Import |
